Description
The 3M CI-1/0-A Compression Splice is a compression connector designed for splicing 1/0 AWG stranded aluminum conductors to 1/0 AWG solid copper conductors. The aluminum connector is designed for reliable electrical and mechanical connections and is compatible with 3M power cable splice systems. The CI-1/0-A is the 3M connector designation corresponding to the 1/0 stranded / 1/0 solid conductor combination shown in your item description. 38.
Dimensions & Specifications:
Manufacturer: 3M
Catalog Number: CI-1/0-A
Type: Compression Splice / Connector
Conductor: 1/0 AWG stranded aluminum / 1/0 AWG solid copper
Connector O.D.: Approximately 0.91″
Material: Aluminum
Plating: Electro-tin plated
Center Stop: Solid center stop
Die: 5/8″ class tooling
Standard: ANSI C119.4
Application: Aluminum-to-copper conductor splicing
Standard Package: 10 EA
Condition & Quality Assurance
We offer products in a variety of conditions, including new, new with damaged or non-original packaging, and used. All items are carefully inspected to ensure full functionality and reliable performance. Cosmetic condition and packaging may vary. Product images are for reference only and may not reflect the exact item shipped.
