Description
The Blackburn PCS67 Compression Pin Adapter is a pigtail-style compression connector designed for connecting #4 ACSR and #4 stranded aluminum conductors to #2 solid aluminum conductors and compatible copper transformer bushings. It features a highly conductive aluminum compression sleeve with a tin-plated copper pigtail, factory-filled with oxide inhibitor to help prevent oxidation and ensure a reliable long-term connection. The PCS67 is designed for overhead secondary and service applications and can be installed using standard compression tooling.
Dimensions & Specifications:
Manufacturer: Blackburn / ABB
Catalog Number: PCS67
Type: Pigtail Compression Pin Terminal
Conductor: #4 ACSR; #4 stranded aluminum to #2 solid aluminum
Pigtail: 0.204″ diameter × 2.5″ long
Pigtail Material: Tin-plated copper
Sleeve: Aluminum
Oxide Inhibitor: Factory-filled Contax
Mechanical Dies: Peach, 5/8, BG, TU
Hydraulic Dies: U-BG, 52
Voltage Rating: 35 kV AC
Application: Aluminum secondary/service conductors to copper transformer bushings
UPC: 783786050413
Standard Package: 500 EA
Condition & Quality Assurance
We offer products in a variety of conditions, including new, new with damaged or non-original packaging, and used. All items are carefully inspected to ensure full functionality and reliable performance. Cosmetic condition and packaging may vary. Product images are for reference only and may not reflect the exact item shipped.
